TITAN Flatbed sidewall semi trailer ,cargo transport semitrailer ,flatbed semitrailer with sidewall

TITAN Flatbed sidewall semi trailer ,cargo transport semitrailer ,flatbed semitrailer with sidewall supplier
TITAN Flatbed sidewall semi trailer ,cargo transport semitrailer ,flatbed semitrailer with sidewall supplier TITAN Flatbed sidewall semi trailer ,cargo transport semitrailer ,flatbed semitrailer with sidewall supplier TITAN Flatbed sidewall semi trailer ,cargo transport semitrailer ,flatbed semitrailer with sidewall supplier TITAN Flatbed sidewall semi trailer ,cargo transport semitrailer ,flatbed semitrailer with sidewall supplier TITAN Flatbed sidewall semi trailer ,cargo transport semitrailer ,flatbed semitrailer with sidewall supplier
Basic Information
Place of Origin: China
Brand Name: TITAN
Certification: ISO,BV.SGS
Model Number: TITAN Flatbed sidewall semi trailer
Minimum Order Quantity: 1 unit
Price: FOB USD 8000-10000
Packaging Details: By bulk cargo ,RORO or 40HQ containers
Delivery Time: 15 Work days
Payment Terms: L/C, T/T
Contact Now
Loading Capacity: 30t-60t ABS System: Optional
Axle: 13T/16T,FUWA/BPW Brand Support Legs: JOST Brand

TITAN Flatbed sidewall semi trailer ,cargo transport semitrailer ,flatbed semitrailer with sidewall



We are the factory.
We can provide competitive price and spot supply.
We offer door-to-door service .



Advantage:

1 Novel design

2 High strength

3 Light trare weight

4 Strong loading capacity



TITAN 3 axles Flatbed semitrailer with sidewall


TITAN Flatbed sidewall semi trailer ,cargo transport semitrailer ,flatbed semitrailer with sidewall 0

TITAN 3 axles Flatbed semitrailer with sidewall

TITAN Flatbed sidewall semi trailer ,cargo transport semitrailer ,flatbed semitrailer with sidewall 1

Manufacturer Titan Vehicle Co.,Ltd
Product type Cargo semi trailer
Outside dimension Length:8500mm-13000mm,width :2500mm,height:2860mm-2900mm
Tare weight 6.5-7.2T
Wheelbase 6560mm+1310mm+1310mm
Loading capacity 30T-60T
Axle 13T/16T,FUWA/BPW Brand
ABS system Optional
Front/rear -/2420
Suspension Mechanical suspension (Germany type or America type) or Air suspension (china brand or BPW brand )
Spring leaf 90(W)mm*13(Thickness)mm*10Layer,optional
Tires 12.R22.5/315 80R22.5/11.00R20/12.00R20 Brand can be optional
Rim 9.00-22.5/8.00-20/8.5-20 China brand
King pin JOST 2.00 or 3.5 inch
Support legs JOST brand
The material of main beam The height of the beam is 500mm ,upper plate is 14mm ,down plate is 16mm,middle plate is 8mm .material is Q345B steel
Floor plate 3mm or can be optional
Side wall 600-1500mm height,or can be do box type, for choose
Brake Chamber WABCO BE 6 RELAY VALVE ;T30/30+T30 Spring brake chamber (TKL brand) ; Two pieces of 45L air tanks or China brand
Electrical system 24v,7 wire harness
Tool box One piece or according to the requirement of buyer
Painting Compete Chassis sand blasting to clean rust ,1 coat of anti-corrosive prime ,2coats of final paint
Chassis name Cargo truck chassis
Note :According to the requirement of buyer
