Place of Origin: | China |
---|---|
Brand Name: | TITAN |
Certification: | COC ,SGS , BV , CCC , COC , ECTIV , PVOC |
Model Number: | fuel tank trailer |
Minimum Order Quantity: | 1 |
Price: | USD 13000-20000/unit |
Packaging Details: | Container, RORO or BULK |
Delivery Time: | 25 work days |
Payment Terms: | L/C, T/T, D/P, Western Union, MoneyGram |
Supply Ability: | 300 Unit/Units per Month |
Type: | Oil Tanker Trailer | Other Name: | Petrol Tanker Trailer |
---|---|---|---|
Material: | Steel | Product Name: | TITAN Oil Tanker Truck Trailers |
Function: | Fuel,or Other Liquid Transportation,Transport Diesel Or Gasoline | Size: | Buyer's Request |
Max Payload: | 45 - 100 Tons | Suspension: | Leaf Spring Suspension,Mechanical / Air |
King Pin: | 90# | Landing Gear: | JOST Brand Two-speed |
Use: | Truck Trailer | Color: | Customers Optional |
Axle: | Optional | Tank Material: | Carbon Steel |
Brake System: | WABCO Relay Valve | Volume: | Optional |
Manhole: | Explosion-proof Type,Optional | Discharge Valve: | 2 Units, 3" Ball Valve. |
Petrol tanker for sale with a tank volume of 11 cubic meters or more is most suitable for multiple compartments. There are two reasons. One is that if the tank volume is small, multiple warehouses will increase the price of tank trucks. The second is that if the volume of the tank is small, a partition must be installed in the tank, which will occupy a certain proportion of the space and reduce the tonnage of the oil. Take gasoline and diesel transportation as an example, the tank body of the oil truck is divided. The two bins are loaded with gasoline and diesel respectively.
After Petrol tanker for sale the are divided into compartments, the oil loading/unloading pipeline arrangement is to install a pipe separately for each tank, and each compartment needs a manhole cover, so when loading and unloading oil, you only need to open each compartments valve.
Brand | TITAN Petrol tanker for sale |
Tank Body | |
Tank Capacity | 40,000-60000liters |
Tank Material | carbon steel |
Compartments | 1 to 7 compartments, based on customer needs |
Discharge | 3” or 4” ball valves |
Discharge Pipes | 2 units |
Ladder | The tank is equipped with a front or rear ladder to facilitate the arrival of manholes. |
Chassis | |
Main Beams | Q345B steel fabricated I beams. |
Landing Gears | JOST |
Axles | 3 axles |
Brake System | WABCO |
Advantage of TITAN Petrol tanker for sale:
1. Tank cover: TITAN fuel tanker trailer use the European standard explosion-proof manhole cover. Including breathing valve, oil and gas recovery valve and anti overflow valve. The outlet at the bottom of the tank is equipped with an emergency shut-off valve - undersea valve, When the tank body collides and rolls over, the tank cover will not be opened.
2. TITAN uses Q345 low carbon alloy steel to make the fuel tanker trailer, which is 5mm thick and very solid. TITAN tank body uses the most advanced welding technology.
3. Quality test: water test, air pressure test. Ensure that the oil and gas will not volatilize under high temperature, and ensure the safety of the vehicle during driving and parking.
Petrol tanker for sale usually adopts by bulk carriers or ro-ro ships. We spray wax on the tank. Cover it with waterproof rain cloth.
Some countries can also ship by container or frame cabinet.
45000 liter Aluminum Tanker Trailer for Sale
3 Axle Aluminum Tanker Truck Trailer for Sale
Through the video below, you can learn about different types of fuel tanker semi trailers (like 3 axle fuel tanker, 4 axle storage tanker trailer, stainless steel tanker trailer, acid tanker trailer, fuel tanker with a flatbed trailer, fuel tank Full trailer)
And the process, testing, packaging and customer feedback, etc.
Stainless steel fuel tanker trailer
If you are interested, welcome to inquire us.we will provide the price, drawing and videos!
