Place of Origin: | China |
---|---|
Brand Name: | TITAN VEHICLE |
Certification: | CCC,SGS,CE,BV,ISO |
Model Number: | flatbed trailer |
Minimum Order Quantity: | 1 set |
Price: | USD 8500-10000/Unit |
Packaging Details: | Container, Roro or bulk cargo |
Delivery Time: | 15 days |
Payment Terms: | L/C, T/T, D/P, Western Union, MoneyGram |
Supply Ability: | 300/month |
Product Name: | TITAN 2 Axle 40 Ft Titan Flatbed Trailer For Sale | Use: | Container Transport |
---|---|---|---|
Type: | Semi-Trailer,Full Trailer,best Price China Manufacturers Flatbed Trailer | Size: | 12400*2500*1550mm,By Customer Needs |
Max Payload: | 40T,50T,60T | Certification: | CCC,SGS,CE,BV,ISO |
Axles: | 3 Axles | Braking System: | Wabco |
Tire: | Optional | Kingpin: | Jost |
Material: | Steel | Suspension: | Mechanical Suspension |
Color: | Yellow, Customers Optional | Axle: | 2 Axle, Customers Optional |
Function: | Transport 20/40ft Container |
After being rust-proofed, the semi flatbed trailers for sale near me is painted with polyurethane paint. So it can be used for a long time in a humid or corrosive environment, further extending its service life.
The semi flatbed trailers for sale near me is equipped with many supporting structures, such as short diagonal supports. They can effectively help the 40 feet flatbed trailer disperse the center of gravity and absorb the impact of the cargo.
The reinforcement of the outriggers increases the bending and torsion resistance of the leveler, ensuring that the tri axle flatbed trailer for sale remains stable even on uneven ground.
The tri axle flatbed trailer for sale can carry heavier cargo by being equipped with a 16-ton axle, achieving safe transportation of heavy and large items and reducing unit transportation costs.
Tri Axle Buy Semi Flatbed Trailers for Sale Near Me
Landing gear are made of wear-resistant materials, which reduces the frequency of replacement of the tri axle flatbed trailer for sale.
High-quality axles reduce deformation and vibration of the 40 feet flatbed trailer when fully loaded or running at high speed.
Overall (L*W*H) | 12500*2500*1530mm |
Frame
|
Material:High strength low alloy Q345 steel |
Main beam height:500 mm | |
Thickness of main beam:upper: 14mm, lower: 16 mm, webplate: 8mm | |
Side Beam Height : 160mm, 16# channel steel | |
Through Beam : 6 items | |
Floor | 3 mm checkered plate |
Brake Pad Width | 220mm |
Axle | 13 tons TITAN axles |
Tire | 12R22.5 Tire |
Rim | 900*22.5, 12 pcs |
Braking System | webco |
Suspension | Mechanical spring suspension, 10 pieces |
King Pin | 2" (50#) or 3.5"(90#) |
Landing Leg | 28T landing leg |
Accessories | 1 tool box ,2 spare tire carrier |
Painting | Sandblasted, anti-rust chassis surface with 1 layer of anti-corrosive primer and 2 layers of top coats |
Color | Any color will be available |
1. In order to reduce the frequent replacement of lamps, the LED lamps on the 40 feet flatbed trailer have a very long service life, usually up to tens of thousands of hours.
2. Compared with thin side beams, wider beams are more resistant to impact. They can reduce the risk of collision during transportation, and improve the dynamic stability of the tri axle flatbed trailer for sale.
3. When turning, the beam design can disperse the pressure of the cargo, enhance the anti-overturning ability of the semi flatbed trailers for sale near me, and enhance driving safety.
4. Compared with thin brake pads, thick brake pads are usually more wear-resistant. It reduces the frequency of brake pad replacement and the maintenance cost of the semi flatbed trailers for sale near me.
5. The automatic adjustment arm design of the 40 feet flatbed trailer makes it unnecessary for the operator to adjust manually. It reduces the time for manual adjustment and realizing more intelligent semi flatbed trailers for sale near me's management.
6. The anti-slip bottom plate design makes it easier for the 40 feet flatbed trailer to fix the cargo during loading and unloading, improves work efficiency, and reduces accidents
7. The relatively long diagonal support may cause a decrease in load-bearing capacity due to excessive deflection. The short diagonal support design of the semi flatbed trailers for sale near me is very helpful in lowering the center of gravity of the vehicle
8. The safety devices and auxiliary equipment of the tri axle flatbed trailer for sale include side protection structures, strong locks and fixings. They will reduce the risk of accidents of the tri axle flatbed trailer for sale.
9. The spare tire is very convenient for maintenance and inspection of the trolley, reducing the cost of tire belt repair or tire replacement
10.When transporting large quantities of goods, the 40 feet flatbed trailer's braking system is sensitive and reliable, making the flatbed truck easier to control.
11.The tri axle flatbed trailer for sale can minimize the squeezing and damage of goods through scientific layout and reasonable fixing methods.
12.The transportation mode of the semi flatbed trailers for sale near me is flexible, including road transportation, or combined transportation by rail or water, helping enterprises to respond quickly to market demand.
13. The transport mode of the semi flatbed trailers for sale near me is flexible, including road transport, or combined transport by rail or water, helping enterprises to quickly respond to market demand.
14.The water tank on the 40 feet flatbed trailer is designed in accordance with relevant standards and can be quickly filled or discharged, ensuring safety during transportation and facilitating deployment.
15.In order to reduce the frequency of maintenance and replacement of the tri axle flatbed trailer for sale, the reinforced crossbeam design reduces the probability of structural fatigue and saves your operating costs.
It is clear to see the details of semi flatbed trailers for sale near me through the video below.
TITAN is glad to offer you spot goods with best price if you contact us.
